Home Page - Industry Application - XRD

XRD领域

KYW600 X-ray tube is an X-ray diffraction tube, which is in use for X-ray diffractometer and crystal analyzer of domestic OEMS and international OEMs. It offers different options on focal spot size and target materials.

KYW600 Diffraction Tube Series

$KYW600 Diffraction Tube Series$

Normal focus		Fine focus
Max Anode Voltage	60kV	Max Anode Voltage	60kV
Max Power	2kW	Max Power	1kW
Anode Material	Cu，W，Mo，Ag	Anode Material	Cu，W，Mo，Ag
1kW Anode Material	Fe，Co，Cr	500W Anode Material	Fe，Co，Cr
Area	1*10mm	Area	0.4*8mm
Line focus	0.1*10mm	Line focus	0.04*8mm
Point focus	1*1mm	Point focus	0.4*0.8mm
